Steering Axle for HOWO
Howo, Sitaier King, And Sitaier Series Heavy Truck
It's applied on HOWO, Sitaier King, and Sitaier series heavy truck produced by the company. The axle has good loading capability
Model
HW08
STR
JW07
Type
Fist Style,IntegratedIBeam
Axle Weight Rating(kg)
7000
6500
Max.Turning Angle
45°
40°
KPI(mm)
1790
1702
1750
King Pin Inclined Angle
3°
5°
Camber
1°
Toe-in(mm)
Bia Ply(11.00-20)
3±1
Radial(11.00R20)
0±1
Track(mm)
2043
1963
1995
Caster
Suspension Center Distance(mm)
850-900
850
900
Brake Type & Size
S cam drum brake 420×160
Wheel Pilot
Hub pilot,wheel stud 10-M22×1.5,B.C.335
Weight(kg)
470
450
Min.Rim(inch)
20
