Plastic Quick Connect
Universal
1) plastic quick connect fittings 2) Size Range:D16-D110. 3) Working Pressure: PN 16 4) Standard:DIN 5) Color:blackan
Description
PP Compression Fittings for PE pressure piping applications. Size range from D16 to D110. Standards Dimensions and characteristics according to EN 712/713/715/911; ISO 3501/3503/3458/3459. To be installed on PE pipes conforming to ISO 11922; DIN 8072/8074; UNE 53131. Also approved for use with PVC flexible hose (contact us for available sizes). Threads (BSP) manufactured according to standard ISO 7; DIN 2999. Also available in ASTM/NPT standards. Working pressure 20ºC D16 - D63: PN 16 (threaded fittings: PN 10) Features Used extensively worldwide. Tested and approved by the world's premier certification institutes. Fast & reliable connections. Perfect sealing under all conditions. Performance: Approved for use with drinking water. Applications: Performance Series: water distribution, irrigation, industry,swimming pools, cable conduits
